Model | IPC-T122-APF28-ECO |
Image Sensor | 1/2.8″ Progressive Scan CMOS |
Max Resolution | 2 MP (1920 × 1080) |
Lens | 2.8 mm Fixed Lens |
Aperture | F2.1 |
Field of View | Horizontal 106.7°, Vertical 57.1°, Diagonal 115.7° |
Minimum Illumination | Color: 0.02 Lux (F2.1, AGC ON), 0 Lux with IR |
Day / Night | IR-cut filter with auto switch |
IR Night Vision | Up to 30 m |
Video Compression | Ultra 265 / H.265 / H.264 |
Frame Rate | 1080p @ up to 25 fps |
WDR | Digital WDR |
Noise Reduction | 2D / 3D DNR |
Image Enhancement | BLC, HLC, Digital Defog |
Motion Detection | Supported |
Privacy Mask | Up to 4 areas |
Audio | Built-in Microphone |
Network Interface | 1 × RJ45 10/100 Mbps Ethernet |
Network Protocols | TCP/IP, UDP, DHCP, RTSP, ONVIF |
Power Supply | DC 12V ±25%, PoE (IEEE 802.3af) |
Power Consumption | Max. 3.5 W |
Weather Protection | IP67 |
Operating Temperature | -30 °C to +60 °C |
Humidity | ≤ 95% RH |
Material | Plastic |
Dimensions | Ø118 × 97 mm |
Weight | Approx. 0.25 kg |
